特性 / FEATURES:

•QDM-26機械式成型機包括送線、衝壓、滑座成型和後 頂出（成型）四大部分，採用機械原理結構構成。

•採用手臂式機械原理，能夠精確的將材料送入衝床的成 形裝置，送料精度控制在0.02mm以內，為您的產品提供 了精度保障。

•衝壓機構可以完成產品成型前的胚料加工，包括沖孔、 凸包、成型前材料切除，以及換折彎成型等。衝壓部份的 使用，可以減少加工工序，節省二次加工成本。

•滑座機構由凸輪、成型滑座和後退車凸輪組成，成形滑 座的角度方向可以任意調整，可以輕易的實現微電子複雜 的晚曲加工。

•後頂出（成型）機構由三組滑塊裝置構成，採用高速凸 輪驅動。可以實現芯摸移動、三維彎曲、工步變動、產品 頂出等功能，可以再快的提高生產效益。

•另外提供了選配零件立體加工座，立體加工座的應用將 會幫您完成複雜的產品成型。

•QDM-26 Mechanical moulding machines lnclude wire. stamping. sliding seat forming and rear top (forming).which are composed of mechanical elements.

•Using arm type mechanical principle. can accurate send material to punch forming device. feeding accuracy control within 0.02mm.ensured the pracision of products for you.

•The stamping mechanism can complete the pre-molding process. lncluding punching.convex. pre furming material. and bending and forming. The use of stamping parts can reduce the processing cost and reduce the processing cost.

•Slide body by CAM.molding of sliding seat and back car CAM. forming can adjust the Angle of the slide direction. can easlly achievemicroelectronics comolex bending. nding

•The rear ejection(forming)mechanism is composed of three sets of sliders which are driven by high speed CAM.lt can realize the function of core mode movement. 3dbenging. step change.

•product roof etc. which can improve the production efficiency faster.in addition. we offer a 3d processing seatforthe optional parts. which will help you to complete the complex producls.
