特性 / FEATURES:

•所有滑座均為獨立伺服驅動，提高調試產品的效率。

•滑座材質采用高耐磨度合金鋼材，延長滑座運轉的使用周期。

•動平衡化的送線轉線機構，高速、精準。采用歐盟CE標 準的防護罩。

•伺服滑座單元可彈性配置，根據客戶實際需要增減，以 達最佳性價比、

•通用的模組界面，以往的充備工裝可以共用，節省了工 裝損耗。

•源自臺灣的設備技術，優化后的操作系統，保證了產品 的一致性。

•也可升級增加多工位卷曲、伺服剪刀和輔助卸料的傳輸 裝置等。

•標配13軸，最大可加裝16軸

•滑座1可左右移動，行程32mm

•All slides are independently servo-driven, improving the efficiency of adjusting products.

•The slide material is made of high-wear-resistant alloy steel, extending the service life of the slide.

•The balanced wire feeding and turning mechanism is high-speed and precise. It is equipped with a protective cover that meets the EU CE standard.

•The servo slide unit can be flexibly configured, with the number of units increased or decreased according to the actual needs of customers to achieve the best cost-effectiveness.

•The modular interface is universal, and the exi s ting comprehensive fixtures can be reused, saving the cost of fixtures.

•The equipment technology originates from Taiwan,and the optimized operating system ensures consistency of products.

•It can also be upgraded to add multi-station winding, servo scissors, and auxiliary unloading transmission devices, etc.

•Standard configuration includes 13 axes, and up to 16 axes can be added.

•Slide 1 can move left and right, with a stroke of 32mm.
